RIDEN RD6024 60V 24A DC to DC Adjustable Regulated Step Down Voltage Bench Power Supply Buck Converter Support Battery Charging

RIDEN
|
SKU0553S-1
$126.99 $0.00( / )
Tax included.Estoque no Brasil. Sem Risco de Taxa. Shipping calculated at checkout.
Features: Powerful device! 60V 24A 1440W max output, suitable for different situations. 2.4 inch big screen, wild view angle, the parameters can be viewed clearly, supports custom color for display. Supports battery charging, it has a battery charging terminal, with all kinds of protections, also supports cut-off current and cut-off...
  • RD6024
  • RD6024W
  • CN

Features:

Powerful device! 60V 24A 1440W max output, suitable for different situations.

2.4 inch big screen, wild view angle, the parameters can be viewed clearly, supports custom color for display.

Supports battery charging, it has a battery charging terminal, with all kinds of protections, also supports cut-off current and cut-off temperature setting to protect your device.

Supports PC software control, you can use our PC software to set the output and view the data, also support APP control by adding extra wifi board.

It supports both keypad control and encoder potentiometer control, it is user-friendly for users.

RD6024-W has WIFI board , RD6024 doesn't have. RD6024-W can use WIFI board to connect APP, also use USB micro cable to connect PC software . RD6024 doesn't have WIFI board, only support PC software by connecting with USB micro cable, no support APP.

Specification:

Model: RD6024/RD6024-W
Input voltage range: 7-70.00V
Output voltage range: 0-60.00V
Output current range: 0-24.00A
Output power range: 0-1440W
Input voltage measurement resolution: 0.01V
Output voltage setting measurement resolution: 0.01V
Output current setting measurement resolution: 0.01A
Battery voltage measurement resolution: 0.01V
Input voltage measurement accuracy: ±(1%+5 digits)
Output voltage accuracy between setting and measurement:±(0.3%+3digits)
Output current accuracy between setting and measurement:±(0.5%+5digits)
Battery voltage measurement accuracy: ±(0.5%+3 digits)
Automatic cut off current value when charging: Set by yourself(higher than 100mA)
Output ripple typical:100mV@12A,150mV@24A VPP
Working temperature range: -10℃~40℃
External sensor Temperature detection range:-10℃~100℃/0℉~200℉
External sensor Temperature detection accuracy:±3℃/±6℉
Constant voltage mode response time: 2ms(0.1A-5A Load)
Constant voltage mode load regulation: ±(0.1%+2 digits)
Constant current mode load regulation: ±(0.1%+3 digits)
Capacity measurement range: 0-9999.99Ah
Energy measurement range: 0-9999.99Wh
Capacity and energy statistical error: ±2%
Buck working mode: (input voltage÷1.1)-1
Over temperature protection: System temperature>80℃
Screen brightness setting: 0-5(6 level in total)
Screen: 2.4inch color HD display
Weight(with package):About 0.72kg
Product dimension: 167*81*69mm
Cooling fan start condition: Output current>8A or System temperature>45℃
Cooling fan shut down condition: Output current <7.9A and System temperature <45℃

File Download:

1. Instruction:
RD6024(W) operation instructon, PC software instruction , APP instruction , APP and PC software download link

2. APP Download:
Android APP, Support android 8.0 -android 10.0;
Android APP Google Play download: Search "Ruideng tech" to download , support Android 8.0 and above phone
IOS APP download: Search "Ruideng tech" to download , support IOS10.0-IOS13.4 System
old phone still use "RDPower" APP

3. Case Assembly:
RD6024 and S800 case assemble instruction

Package Included:

1 x RD6024/ RD6024W Power Supply

Type:

Power Supply & Tester

Vendor:

RIDEN

Model NO.:

RD6024, RD6024W

Ship From:

CN

SKU:

SKU0553S-1
