2024 NEW TOOLTOP ET15S 2 In 1 256*192 Thermal Imager Multimeter 20000 Counts 3.5 Inch Touch Screen Electric Circuit Automobile Inspect IR Thermal Camera Multimeter

Features:

High-resolution images: The device uses sensors with an image capture frequency of 25Hz and image pixels of 256 × 192px to provide clear and detail-conscious thermal images.

User interface friendly: 3.5-inch LCD HD touch screen, 320*480 high resolution, small trouble clearly visible. 15 color swatches to choose from. Type-C USB port to ensure interactive operations.

One machine multi-purpose. Built-in imager, multimeter function. Equipped with an extensive parameter array, the integrated multimeter can measure readings up to 1000V DC and 750V AC inputs, current measurements up to 10A, and also includes high measurement resistance, capacity, diode, and duty cycle ranges. The field of view is adjustable between 0.1 and 0.99, with the default being 0.95 for a variety of applications.

Multipoint temperature measurement. 49,152 points can be detected at the same time, rapid fault detection, no omissions. High and low temperature automatic capture, three point temperature measurement is more accurate.

Small size, light weight, easy to carry. Wide application scenarios. Suitable for floor heating leakage, power inspection, electronic maintenance, industrial temperature measurement, field search and rescue, petrochemical and other fields.

Specifications:

Sensor: Vanadium oxide (VOx)
Image capture frequency: 25Hz
Module output pixel: 256x192
Display image resolution: 427 x 320
Field of View (FOV) : 50.0°(H) × 37.2°(V)
Emissivity: 0.1-0.99 adjustable, default 0.95
Measuring temperature range: -20℃ ~ +550℃
Mode: Automatic gain
Color plate: White heat, black heat, fusion 1, Rainbow, fusion 2, iron red 1, iron red 2, dark brown, Color 1, color 2, Fire and Ice, rain, green heat, red heat, dark blue
Temperature measurement error: ±2℃ or ±2%
Display temperature accuracy: 0.1℃/0.1℉

Multimeter Parameters：

Maximum DC input voltage: 1000V
Ac maximum input voltage: 750V
Maximum current measurement: 10A
Resistance Maximum measured resistance: 99.99MΩ
Maximum measured capacitance: 199.99mF
Duty cycle measurement range: 0.1% ~ 99.9%
Diode measurement range: 0V ~ 3V
Maximum resistance of on-off detection: 199.99Ω
Display numbers: 19,999 words, updated about 3 times per second

Other Parameters of The Device:

Display screen: 3.5 "320*480 resolution
USB port: Type-C USB
TF card maximum capacity: 64G
Image format: BMP file
Battery: removable 18650 lithium battery
Storage temperature: -20 ~ 60℃ (-4 ~ 140℉)
Operating temperature; 0 ~ 50℃ (32 ~ 122℉)
Working humidity: < 85%RH (non-condensing)
Product size :134 mm * 64mm * 28 mm
Product weight; 150g, 198g (battery included)

Notes:

1. The ET15S option only includes the TOOLTOP ET15S Thermal Imager Multimeter.
2. The ET15S Pro options include TOOLTOP ET15S Thermal Imager Multimeter and ET15S Micro Lens.

Package list:

Model A: ET15S

1 x ET15S Thermal Imager Multimeter

1 x Instrument Storage Bag

1 x Multimeter Probe

1 x Data Line

1 x Product Manual

1 x Packaging Box



Model B: ET15S PRO

1 x ET15S Thermal Imager Multimeter

1 x Instrument Storage Bag

1 x Macro Lens

1 x Multimeter Probe

1 x Data Line

1 x Product Manual

1 x Packaging Box
